Steel Rod End Bearing For Cars Trucks With Female Thread

Product Description

Top Bearings is Steel Rod End Bearing For Cars Trucks With Female Thread manufacturers and suppliers in China who can wholesale Steel Rod End Bearing For Cars Trucks With Female Thread. We can provide professional service and better price for you. If you interested in Steel Rod End Bearing For Cars Trucks With Female Thread products, please contact with us. We follow the quality of rest assured that the price of conscience, dedicated service.

Product Parameter

Material:	Steel / Steel	Dimension:	14M1421MM
Precision Rating:	P0,P6,P5,P4,P2	Weight:	0.22KG
Clearance:	C0,C2,C3,C4,C5	Vibration:	Z1V1, Z2V2 And Z3V3
High Light:	spherical bearing rod ends, swivel rod ends

Model Number	PHS16
Brand Name	OEM
Dimension	14M1421MM
Weight	0.22KG
Type	Rod end bearing
Material	Steel/steel
Clearance	C0,C2,C3,C4,C5
Vibration	Z1V1,Z2V2 and Z3V3
Precision Level	P0,P6,P5,P4,P2(ABEC1, ABEC3, ABEC5, ABEC7, ABEC9)
Guarantee	One year.
Certifications	ISO 9001:2008
Package	Box, Carton, Wooden Case, Plastic Tube or Per buyers requirerment
Place of Origin	China (Mainland)
MOQ	1PCS
Service	(1) Prompt Delivery
	(2) OEM
	(3) Buyer Label accepted
	(4) Follow up and maintenance
Payment Term	TT

Steel - Steel Rod End Bearing PHS16 For Cars , Trucks With Female Thread

Quick Detail:

1) Rod end bearing PHS16

2) Bearing material :Steel-steel

Abundant stock ,Quick Delivery

3) Brands: OEM

Description:

Rod end bearing PHS16

Rod ends requiring maintenance

Rod ends consist of an eye-shaped head with integral shank which forms a housing for a spherical plain bearing. As a rule, rod ends are available with left or right-hand female (internal) or male (external) threads according to ISO 965/1:1980. Where rod ends are needed for specific applications - primarily those where a rod end is attached to the end of a piston rod or at the base of a hydraulic cylinder - rod ends are available with slotted shank and compressible threaded section or with a "welding shank" i.e. a shank suitable for welding to another component.

rod ends which require maintenance are available as standard with the sliding contact surface combinations steel/steel and steel/bronze. Both types of rod end require regular republication. Steel/steel rod ends have sliding contact surfaces which are hardened, phosphate and treated with a running-in lubricant. They are very resistant to wear and therefore particularly suitable for applications where heavy loads of alternating direction have to be accommodated. Steel/bronze rod ends have a hardened and chromium plated inner ring and a bronze outer ring. Their performance under conditions of lubricant starvation is therefore very good.

Rod ends with a left-hand thread are identified by an L in the designation prefix, otherwise the rod ends have a right-hand thread. For example, rod end SILA 40 ES has a left-hand thread whereas rod end SIA 40 ES has a right hand thread.

The following types of rod ends requiring maintenance are available:

Steel/steel rod ends with female thread

1. steel/steel rod ends with female thread for hydraulic cylinders

2. steel/steel rod ends with male thread

3. steel/steel rod ends with welding shank

4. steel/bronze rod ends with female

5. Thread steel/bronze rod ends with male thread

Applications:

Cars

Trucks

Race cars

Motorcycles

Lawn tractors,

Boats

Industrial machines

Go-karts

Radio-control helicopters

And many more applications

Related Model:

Number	Dimensions mm														Load ratings KN		Weight
	d	d3	B	C1	W	l3	d2	l4	h1	l5	d4	d5	dk	α°	C	Co	≈kg
	d	d3	B	max	W	min	max	max	h1	max	max	max	dk	≈	C	Co
PHS5	5	M5	8	6	9	14	18	36	27	4	8.5	11	11.11	13	3.25	5.7	0.016
PHS6	6	M6	9	6.75	11	14	20	40	30	5	10	13	12.7	13	4.3	7.2	0.022
PHS8	8	M8	12	9	14	17	24	48	36	5	12.5	16	15.875	14	7.2	11.6	0.047
PHS10	10	M10	14	10.5	17	21	26	56	43	6.5	15	19	19.05	13	10	14.5	0.077
PHS12	12	M12	16	12	19	24	30	65	50	6.5	17.5	22	22.225	13	13.4	17	0.1
PHS14	14	M14	19	13.5	22	27	34	74	57	8	20	26	25.4	16	17	24	0.16
PHS16	16	M16	21	15	24	33	40	84	64	8	22	28	28.575	15	21.6	28.5	0.22
PHS18	18	M18X1.5	23	16.5	27	36	44	93	71	10	25	31	31.75	15	26	42.5	0.32
PHS20	20	M20X1.5	25	18	30	40	48	101	77	10	27.5	35	34.925	14	31.5	42.5	0.42
PHS22	22	M22X1.5	28	20	32	43	54	111	84	12	30	38	38.1	15	38	57	0.54
PHS25	25	M24X2	31	22	36	48	60	124	94	12	33.5	42	42.85	15	47.5	68	0.73
PHS28	28	M27X2	35	24	41	53	66	136	103	14	37	46	47.6	15	58	75	0.98
PHS30	30	M30X2	37	25	46	56	70	145	110	15	40	50	50.8	17	64	88	1.1

Steel - Steel Rod End Bearing PHS16 For Cars , Trucks With Female Thread 0
