Carbon Steel Pap Du Bushing Slitted Type Tin Plating
As the professional manufacturers, Top Bearings would like to provide you high quality Carbon Steel Pap Du Bushing Slitted Type Tin Plating. And we will offer you the best after-sale service and timely delivery.
Send Inquiry
Product Description
As the professional manufacturers, Top Bearings would like to provide you high quality Carbon Steel Pap Du Bushing Slitted Type Tin Plating. And we will offer you the best after-sale service and timely delivery.
Product Parameter
|
Material: |
Stainless Steel + Bronze+ Ptfe |
Supply Ability: |
Flanged Bronze Bushings, Bronze Thrust Washers, Self Lubricating Bronze Bushings |
|
Characteristic: |
Low-maintenance And Maintenance-free Plain Bearings |
Production Feature: |
Bushes, Collar Bushes, Washers, Strips Or Special Designs |
|
Certification: |
STEEL BACKED BUSHING, DIN 1494 / ISO 3547, LOW-MAINTENANCE |
Size: |
Customized Size,Customized Request, All Standard, As Per Customer's Request |
|
Lubricating: |
Oilless |
Packaging Details: |
Export Standard Packing |
|
High Light: |
Carbon Steel Du Bushing,Pap Du Bushing,Tin Plating Self Lubricating Bearings |
||
Carbon Steel Pap Du Bushing Slitted Type Tin Plating
Pap Bushing Du Bushing Slitted type, carbon steel Bushes supplier.Pap Bushing Du Bushing Slitted type Bearings supply Metal + Sintered Bronze POM sheets. With Steel Backing, Bushings thrust washers and strips - Bearings, Same-Day ShipmentsMetal-polymer bearings DU BUSH WITH BRONZE BACKING for dry and lubricated applications in corrosive environments. Cylindrical & flanged bushes, thrust washers.
Flanged Metal-Polymer Anti-Friction Plain Bearings
|
TYPE |
ID |
OD |
L |
|
PAP |
30 |
34 |
25 |
|
PAP |
25 |
28 |
25 |
|
PAP |
12 |
14 |
15 |
|
PAP |
8 |
10 |
10 |
|
PAP |
10 |
12 |
12 |
|
PAP |
10 |
12 |
10 |
|
PAP |
16 |
18 |
20 |
|
PAP |
20 |
23 |
20 |
|
PAP |
6 |
8 |
8 |
|
PAP |
14 |
16 |
20 |
|
PAP |
16 |
18 |
25 |
|
PAP |
20 |
23 |
25 |
|
PAP |
8 |
10 |
12 |
|
PAP |
12 |
14 |
10 |
|
PAP |
20 |
23 |
10 |
|
PAP |
45 |
50 |
30 |
|
PAP |
45 |
50 |
50 |
|
PAP |
14 |
16 |
10 |
|
PAP |
50 |
55 |
50 |
|
PAP |
32 |
36 |
40 |
|
PAP |
40 |
44 |
20 |
COMPOSITION
Metal-Polymer Composite Material
Bronze Back + Porous Bronze Sinter +
PTFE + Lead
competitive prices for below bearing bushing products to start our cooperation with you
PAP 1615 P10 PAP 1620 P10
PAP 2015 P10
PAP 2525
PAP 1212
PAP 2520
PAP 2020 P10
PAP 1640 P10
PAP 1830 P10
Metal-Polymer Bronze Backed PTFE Plain Bearing
AVAILABILITY
Bearing forms available in standard dimensions
Cylindrical bushes
Flanged bushes
Sliding plates
Bearing forms made to order: standard forms in special dimensions, thrust washers, flanged thrust washers, half-bearings, special shapes obtained by stamping or deep drawing, customized bearing designs
CHARACTERISTICS
DU BUSH WITH BRONZE BACKING offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
Bushing material suitable for lubricated applications
Anti-friction bearing suitable for linear, oscillating and rotating movements
Approved to standard FAR 25.853 and FAR 25.855 (Federal Aviation Regulations) and ASTM E162:2016 – surface flammability testing for aircraft interior applications
Tested acc. to ASTM E595/ECSS-Q-ST-70-02C - Outgassing properties of materials used in Spacecraft equipment
Approved to standard DIN EN 1797 and ISO 21010 (Cryogenic Vessels – Gas/Material Compatibility) for piping, valves, fittings and other components in both gaseous and liquid oxygen for up to maximum temperature of 60°C and oxygen pressure of 25 bars. Contact TOP BEARINGS for further details.
ADVANTAGES
Improved energy efficiency with the low friction performance of PTFE-enriched overlay;
Extended service life with a high wear-resistant bronze layer;
Zero maintenance as self-lubricating bearings can operate dry without grease;
Greater reliability than bimetallic bearings by avoiding potential shaft/bearing seizure under boundary lubricated conditions and frequent stop/start operation;
Compact, lightweight designs with thin-wall bearing construction;
Reduced noise with no metal-to-metal contact between the bearing and the shaft;
Quick, simple assembly without expensive mounting tools.
Usage Range
|
dry |
very good |
|
oil lubricated |
good |
|
grease lubricated |
fair |
|
water lubricated |
good |
|
process fluid lubricated |
fair |
Physical & Mechanical Properties
|
Items |
Value |
Unit |
|
Thermal Conductivity |
18 |
W/mK |
|
Maximum Operating Temperature |
280 |
°C |
|
Minimum Operating Temperature |
-200 |
°C |
|
Compressive Yield Strength |
300 |
N/mm2 |
|
Maximum Static Load |
140 |
N/mm2 |
|
Maximum Dynamic Load |
140 |
N/mm2 |
|
Maximum Sliding Speed -dry |
2.5 |
m/s |
|
Maximum PV Factor-dry, continuous operation |
1.8 |
N/mm2 * m/s |
|
Maximum PV Factor-dry, intermittent operation |
3.5 |
N/mm2 * m/s |
|
Coefficient of friction -dry |
0.02-0.25 |
|
|
Coefficient of friction -oil lubricated |
0.02-0.12 |
